G-Star Stencil Printer: Cost-Efficient and High Precision SMT-Printing
G-Star Stencil Printer:
Cost-Efficient and
High Precision SMT-Printing
Cost-Efficient and
High Precision SMT-Printing
The G-Star stencil printer is a fully automatic, high-precision, and
cost-effective solution for modern SMT production lines. Equipped with advanced CCD camera technology and motorized PCB clamping system, it delivers excellent print quality with minimal operator effort.
With its exceptional high alignment and process accuracy, the G-Star is perfectly suited for fine-pitch pads and demanding solder paste printing applications. The integrated SPI closed-loop system continuously monitors the printing process and automatically adjusts parameters when
required – ensuring maximum process stability in your SMT assembly line.
With a core cycle time under 8.5 seconds and flexible PCB handling
(up to 400 mm x 340 mm), the G-Star is ideal for both high-volume and high-mix manufacturing. Featuring automatic solder paste dispensing, 2D paste inspection, and full Industry 4.0 connectivity, this SMT printer delivers a future-proof solution with outstanding
price-performance.
Why the G-Star Stencil Printer is the Best Choice for Your SMT-Line:
Why the G-Star Stencil Printer is the Best Choice for Your SMT-Line:
Designed by Freepik
Optional Features
SPI Closed-loop Connection
The system automatically adjusts the solder paste deposition based on SPI feedback regarding print quality. Compatible with software from TRI, Koh Young, Pemtron, Parmi, Saki and many others.
PCB Clamper
The PCB clamper is a combination of retractable top clamp and motor controlled side clamp, uniquely designed by GKG (patented). This design enables secure fixation of all substrate types and ensures repeatable accuracy and printing stability.
Industry 4.0 Ready
Through machine status, parameters can be uploaded automatically. Designed to support customers’ advancement towards Industry 4.0 intelligence production, G-Star provides seamless connection with users’ MES system, enhancing product traceability and maintenance needs.
Stencil Aperture Inspection System
Using panel light installed at the top and CCD camera below to inspect stencil apertures. It automatically detects the clogging of stencil apertures to eliminate poor quality stencil being used, ensuring high-quality printing right from the start.
Paste Rolling Diameter Monitoring System
Tracing solder paste rolling diameter in real time and trigger the auto dispensing if it falls below 10 mm. This eliminates insufficient solder paste on stencil and keep the paste rolling speed within optimum range to achieve best printing result with this smt printer.
Auto Paste Dispensing
The paste is automatically dispensed across the entire squeegee length. Completely eliminates the wastage of solder paste overflowing at the edges of the squeegee.
Your SMT Production in Focus: Our Turnkey Solutions
Your SMT production deserves the optimal combination of efficiency, precision, and quality. Our turnkey SMT lines provide fully integrated solutions with perfectly synchronized machines and cutting-edge technologies to ensure maximum performance and process reliability.
Discover more about our complete SMT line solutions and get expert advice from our team to find the perfect setup for your production needs.
Did You Know? We also have a dedicated webshop where you can find in-depth information, complete technical specifications
and a wide range of additional equipment for your production line. Get expert advice or place your order quickly and securely.
If you don’t have access yet, you can register for free right here:
